TPU Consumer Electronics Data Line Material

Consumer electronics TPU Data Cable Materials

This product is made of polyether polyurethane elastomer as the base material, adding high-efficiency flame retardant and other processing aids, and is made by mixing, plasticizing and granulating.halogen-free, high flame retardant grade, high resilience, hydrolysis resistance, temperature resistance, weather resistance, oil resistance。

Fully supports conventional data cables to pass UL758/1581VW-1 combustion test, 1000Hrs high temperature and humidity test (85C/85%, 1000Hrs), oil resistance (IRM902, 60℃, 168Hrs), chemical resistance, mildew resistance and other environmental and life tests; the preferred material for high-end consumer electronic products supporting cables.

Application：

Consumer Electronic Data Cables, Household Appliance Wires

As a material for consumer electronic data cables, TPU (thermoplastic polyurethane) is widely used due to its unique properties. TPU has high elasticity, high flexibility, high toughness and good feel, which makes it very popular in areas such as data cables and charging cables. Here are some key applications and characteristics of TPU in the field of consumer electronic data cables:

Abrasion resistance and weather resistance: TPU has excellent abrasion resistance and weather resistance, and is suitable for data cables that are frequently moved or exposed to different climatic conditions. This property is especially important for cables that need to be bent and twisted frequently.

Chemical resistance: TPU has good resistance to chemicals such as oils, acids, and alkalis, and is suitable for use in changing environments, such as places such as kitchens or laboratories where chemicals may be exposed.

Hydrolysis resistance: TPU has strong hydrolysis resistance and can maintain its physical properties even in humid environments, which is an important feature for data cables that are often used outdoors or in humid environments.

Environmental protection: TPU is a mature environmentally friendly material that does not contain halogens and does not produce toxic fumes when burned, meeting modern environmental protection requirements.

Softness and comfort: The softness and comfort of TPU make it an ideal choice for devices that come into direct contact with the human body, such as headphone cables and mobile phone charging cables.

Processing performance: TPU materials are easy to process and can be made into various shapes of data cable sheaths through extrusion molding, injection molding, etc., and the yield rate is high during the processing process.

Transparency and aesthetics: TPU materials can be made into transparent or translucent products, which provides a beautiful appearance option for data cables and also facilitates users to view the internal structure.

Special performance modification: TPU can be modified to obtain special properties, such as UV resistance, mildew resistance, hydrolysis resistance, chemical resistance, etc., to meet special application requirements.

In the field of consumer electronics, the application of TPU materials is not limited to data cables, but also includes products such as smart bracelets, mobile phone protective cases, and tablet protective cases. With the development of technology and market demand, TPU materials have broad application prospects in the field of consumer electronics, especially in the 5G era, the increase in data transmission speed and the enhancement of equipment performance will further promote the use of TPU materials in electronic devices.

Product Parameters

Testing Items	VALUE	Typicalvalue	UNIT	Method
Specific Gravity	1.2±0.05	1.22	g/cm3	GB/T 1033
Tensile strength	≥25	27	MPa	GB/T 1040
Elongation at break	≥400	589	%	GB/T 1040
Tear strength	≥25	30	N/mm	CQC1103-2015 Excursus B
TS Retention	≥70	86	%	GB/T2951.12
EB Retention	≥70	95	%	GB/T2951.12
TS Retention	≥70	80	%	GB/T2951.12
EB Retention	≥70	89	%	GB/T2951.12
UL Temperature rating	90	90	℃	UL
Brittleness Temperature	≤-40	≤-40	℃	GB/T5470
FLAME CHARACTERISTICS
Flammability rating	V0	V0	/	UL
ELECTRICAL PROPERTIES
VolumeResistivityat20℃	≥1.0* 1014	4.5* 1014	Ω .cm	IEC 60093
（IRM902,100℃*168H)
TS Retention	≥60	70	%	—
EB Retention	≥60	75	%	—
